MINDMAN MVSC-300-3E2P-NC-DC24-G – 3/2 NC, 24VDC, Pressure Centre, Double Solenoid, Series MVSC 300 Solenoid Valve

Part Number: MVSC-300-3E2P-NC-DC24-G Manufacturer: Mindman
Enquire about this product:

Description

Mindman Series MVSC 300 is a 5 ported 4 Way Directional Control Valve used to move cylinders or actuators. Supply pressure must be supplied to the center port on the side of the valve with the 3 ports. The outlet ports on the opposite side are connected to each side of a cylinder or actuator. The pressure will hold the cylinder in one position while the other side of the cylinder is exhausted.

Mindman Part Reference: MVSC-300-3E2P-NC-DC24-G

Additional information

Function

3/2
Manufacturer

Mindman
Port Connection

RC 3/8
Voltage

24V DC
Ambient Temperature Max

50DegC
Working Pressure Max

8 Bar
